Product Description
AEM Performance Electronics E85 Fuel Pump (PN 50-1200) for high performance naturally aspirated and forced induction EFI vehicles. The AEM E85 Fuel Pump flows 340 LPH (84 GPH) at 40 PSI. AEM's E85 Fuel Pump features robust internal construction that is designed to withstand the low lubricity characteristics of ethanol and methanol fuels, and has been tested to work with ethanol fuels up to E100, methanol fuels up to M100 and all types of gasoline.
The AEM E85 Fuel Pump is designed for in-tank mounting and features a compact 39 MM diameter that fits most applications. It features an offset inlet design that eases installation and includes a wiring harness, pre filter, internal fuel hose and clamps, end cap and rubber buffer sleeve. Every AEM (PN 50-1200) E85 Fuel Pump is tested to flow 340 LPH (84 GPH) at 40 PSI before it is packaged for sale.
PRODUCT FEATURES:
* Tested and compatible with ethanol fuels up to E100, methanol fuels up to M100 and all types of gasoline.
* Designed for high output naturally aspirated and forced induction EFI vehicles.
* In-Tank design.
* Each pump is tested to flow 340 LPH @ 40 PSI.
* 39 MM diameter fits most applications.
* Offset inlet design eases installation.
* Kit includes fuel pump, rubber sleeve and end caps, pre filter, hose, clamps and flying lead.
* Pump body size 39 MM diameter x 81 MM length.
---
TECHNICAL SPECS:
* Weight: 12.5 OZ. (354 Grams).
* Outside Diameter: 39 MM OD.
* External Materials: Black plated steel with laser etching, green end caps.
* Inlet Fitting: 7.7 MM ID, 11.0 MM OD. Offset Inline.
* Outlet Fitting: 8 MM hose clamp. Offset.
* PRV Activation: 80 PSI.
* Impeller Design: Single Scroll Ceramic Turbine.
---
VOLTAGE SPECS:
* Connector Terminal: 6 MM Spade (Pos/Neg).
* Min Voltage Input: 6 Volts.
* Max Voltage Input: 18 Volts.
* Current Draw (40 PSI): 12 Amps (13.5 Volts).
* Current Draw (80 PSI): 15 Amps (13.5 Volts).
* Fuse: 15 Amps (13.5 Volts), 20 Amps (13.5 Volts) MAX.
---
FITS: UNIVERSAL APPLICATIONS
